CNC Automatic Plate Circular Sawing Machine Precision Sawing
Description
Hydraulic clamp and pressing device can firmly clamp the workpiece, prevent the saw blade from vibrating, increase the sawing accuracy, and thus increase the service life of the saw blade.
The servo motor cooperates with the ball screw feeding system, which can accurately and quickly send the material to the exact position, improving work efficiency
The saw blade cutting feed system uses a servo motor and rotates with the ball screw to ensure the speed of the saw blade movement and increase the accuracy and stability of cutting.
The sawing foundation is in the lateral suspension structure; the guide device is arranged with double—row roller type straight slide rail.
In the travelling of sawing foundation, the grinding gear, rack and servo motor are arranged to guarantee the compatibility of sawing speed.
Except for the fioating rollers, all other contents on the working platform are made of chromium-platedsteel plate in order to avoid scratch of materials.
The machinery framework is in the heavy- -duty structure so that equipment enjoys stable operation.
The suspended feeding clamp claw features as air pressure driving and clamping.
The driver of feeding mechanism is in the structure of servo motor + gear andrack.
Model: HL-10CNC automatic high-speed precision aluminum plate circular saw machine
▲ HL represents the model of Aluminum plate sawing machine in Heineda.
▲ 10 represents the size of the aluminum plate sawing machine, 10 can be sawd in width of 3300 mm.
▲ CNC represents this aluminum plate saw cutting machine for numerical control automatic model.
Technical specifications and parameters
| Model | HL-10CNC | |
| Floating platform | 2 seats | |
| Sawing length | 3300MM | |
| Sawing width | 3300MM | |
| Sawing height | 160/200 | |
| Saw blade outer diameter | 550/630 | |
| Clamping gripping | 8 groups | |
| Rotational speed of Sawing blade | 3900 | |
| Motor of sawing blade | 22/30 | |
| Feeding servo motor | 3 | |
| Travelling motor | 2(AC) | |
Obtained a number of patent certificates
Our company
We have been focusing on the innovation and research of computer beam saws, CNC drilling machines, edge banding machines, CNC routers, as well as machine assembly and software integration, providing a full range of CNC furniture equipment and automated production solutions. With good technological innovation, good production management and high-quality service, the products are exported to many countries. In the future, we will continue to focus on the research and development and manufacture of panel furniture machinery, and welcome more friends to know us and become partners to create a better future.
Packaging Details
Foam inside ,plastic film outside ,wooden box is optional.
| Quantity(sets) | 1 - 1 | 2-5 | >5 |
| Est. Time(days) | 15 | 30 | To be negotiated |
FAQ
Q: Are you manufacturer ?
A:Yes, we have our own factory and we promise direct sales at a
competitive price. Welcome to visit our factory at any time.
Q: Can I get a machine according to my own requirements?
A: Sure.We accept OEM and ODM.
Q: This is the first time I use this kind of machine, is it easy
operate?
A: There are guide video that show how to use machine and english
instruction book send to you with machine. If there is still have
any question, we will provide free professinal guide for you until
you could use machine well.
If you haven't found the machine you need, don't hesitate to contact us too. We will do best to give you the best suggestion.
|
|
